Automatic Shrink Sleeve Labeling Machine

Product Categories

Automatic Shrink Sleeve Labeling Machine
PLANET MACHINE offers a full range of shrink sleeve label applicators for low, medium, and high-speed production environments. All of our shrink material applicators are capable of performing up to five key sleeving applications: Full body sleeves, Full body over-the-cap sleeves, Partial body sleeves, Tamper evident bands, Multi-packs etc Paima Packaging also offers wide label format models capable of handling label widths up to 900mm. our shrink sleeve label applicators and machine systems are used in a wide variety of industries including fluid milk, craft beer, ready-to-drink beverages,
cosmetics, home care products, and personal care products. Their flexibility and reliable performance make them one of the best values in the shrink sleeving industry.
GET A QUOTE
GET A QUOTE

Share:

Description
Video

This machine uses large quantities of aluminum and high strength, the corrosion-resistant stainless steel, so that the overall structure of the machine more durable and it’s performance is more modular, user-friendly design makes the adjustments more easily and change style much simpler. Using the man – machine interface In the control system, which is easy to learn and under-stand.


Product Parameters

ModelPM-300PM400PM-250DPM-50G
Input Power4kw4kw6kw2.5kw
Input voltage380/220V/AC 3phase380/220V/AC 3phase380/220V/AC 3phase380/220V/AC 3phase
production Efficiency300bottles/min400bottles/min2*150bottles/min3000bottles/min
Size of the host machine2600L×1100W×2200H2600L×1100W×2200H3200L×1200W×2070H1700L×900W×2000H
Bottle diameter28mm-120mm28mm-120mm28mm-125mm500mm-600mm
Length of label30mm-250mm30mm-250mm30mm-250mm60mm-160mm
Thickness of label0.03mm-0.13m0.03mm-0.13m0.03mm-0.13m0.03mm-0.13m
Paper tube diameter5”-10 (Free adjustment)5”-10 (Free adjustment)5”-10 (Free adjustment)5”-10 (Free adjustment)
