L type shrink wrapping machine

Product Categories

L type shrink wrapping machine
Shrink Wrapping is a process that involves the application of temperature sensitive films. When heat is applied to the film it shrinks tightly to whatever it is covering. Shrink wrapping equipment is available for a variety of product sizes and in both automatic and semi-automatic formats. At Planet Packaging, we can help you find the right shrink wrap machines that are tailored to your operation’s unique needs.
GET A QUOTE
GET A QUOTE

Share:

Description
Video

Applying imported PLC, which can control the machine automatically, with stable performance, precise control. With the capacity of feeding and sorting bottles, shrinking and cooling shaping automatically. Inductive switch control the feeding of film, which can control the length of film and reduce the consumption. Imported traducer control for the convey motor, which can can realize step-less speed regulation. Advanced Helical air circulation structure, three layer of heat insulation treatment, and energy saving. Strengthened cooling shaped tunnel, which can shaped the package quickly and transported conveniently.


Product Parameters

Model PM-LW10
Input Power24kw
Input voltage380/220V/AC 50 HZ 3phase
Packaging Speed8-10bags/min
Max Package DimensionL600mm*W400mm*H350mm
Transfer Belt Width304mm
Sealing and Cutting Time/Temperature0.5-1.5s 14℃-16℃
Operating Air Pressure0.6-0.8 Mpa
Thermal Shrinkage Passage DimensionL1800mm*W650mm*H400mm
Dimension for The Whole UnitL6500mm*W3200mm*H2100mm
